Home  >  Lifts and Mounts  >  Projector Lifts  >  Scissor Lift SL

Scissor Lift SL

The Scissor Lift SL offers reliable and stable lifting for heavy projectors, and extensions up to 12'.

An excellent choice for heavy projectors, Scissor Lift SL supports larger, brighter video projectors up to 12 amps and is available in 5 models with varying lifting capacities. Three sets of scissors provide lateral and front-to-back projector stability. Longer extension positions make it easier to maintain the projector during shows and service. Set two show positions easily while still allowing fully up and down positions for storage or maintenance. Set positions are retained even if power is lost. The SL can provide power to the projector with either a 115V or 240V UL receptacle outlet.

Product Specs

  • Available for 115V and 240V U.S. applications.
  • 5 models available with SL4: 4' (122 cm), SL6: 6' (183 cm), SL8: 8' (244 cm), SL10: 10' (305 cm), and SL12: 12' (366 cm) extensions. Size affects lifting capacity. Check Submittal or Installation Instructions for exact capacity on size.
  • Features several built-in control capabilities as standard, including RS232, RS485, and more. RF or IR controls optionally available.
  • Smaller projectors can fit within 2’ x 2’ (61 cm x 61 cm) ceiling grid.
  • Optional Environmental Airspace Housing to isolate projector from environmental airspace above ceiling.
  • Optional ceiling closure panel available in white (standard) or black.
  • Ceiling finish kit optional. Kit includes ceiling trim ring and closure panel (order when Airspace Housing is not required).
  • Optional universal-style bracket for easy attachment of a variety of projector models.
  • Installation of factory installed cables for video and projector control available.
  • Wall switch and service key switch, standard.
  • Lift finish available in white (standard) or black.
  • Entire product is UL Listed to meet strict building code requirements for products recessed above the ceiling.

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

Skip Navigation Links.

Retail Pricing Table

Display part numbers with 110V or 220V motors.

ModelMax. Lowering
Distance		Retracted HeightLift
Capacity (lbs.)		Net
Weight (lbs.)		Shipping
Weight (lbs.)		Part No.
110 V		U.S. Retail
Price		Dealer Net
Price
SL44’8"13288113300270$8980
SL66’10"12596123300271$9598
SL88’12"118104131300272$10526
SL1010’14"109111141300273$11146
SL1212’16"100118146300278$11766

Dimensions (WxD) Max Projector Size (WxD) Lowering Distance Unit Weight
Scissor Lift SL with SL closure 22 1/32" x 22 1/32" 18-1/4" x 21-13/16" 48" - 144"
Scissor Lift SL with B closure 30 1/4" x 30 1/4" 28-1/16" x 25-3/8" 48" - 144"
Scissor Lift SL with E closure 30" x 40 1/2" 25-1/8" x 38-3/16" 48" - 144"
Scissor Lift SL with U closure 35 1/8" x 35 1/8" 34-7/8" x 26-1/8" 48" - 144"

Related Products & Accessories

CONTROLS for this lift.
ACCESSORIES for this lift.
Scissor Lift SLX
