Foundation Mount System for Barco XT

The Foundation Mount System for Barco XT features a modular design with alignment tools for precise and easy LED video wall installation.

Engineered for greater precision and time savings, the Foundation Mount System for Barco XT LED panels offer an economical, configurable wall mount with installer-friendly features. Built-in precision simplifies challenges, ensuring a faster, more accurate installation. Save time, gain precision—included alignment fixture tools position critical components for a flawless LED panel installation, reducing the need for realignment. Keyhole attachments and high-precision Y and Z-axis adjustments enable quick, precise installation, even on non-flat surfaces.


Product Specs

  • Designed specifically for Barco XT LED panels.
  • Standard array sizes range from 4x4 to 12x12, and 15x5.
  • Available with textured black powder coated trim or without trim.
  • Modular design allows for any array size no cutting or trimming on site.
  • Seismic rating: Draper is able to provide seismic rated mounting solutions when specified in advance. Please contact your sales team if seismic rating is required for your project.

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

Skip Navigation Links.

Retail Pricing Table

Part NumberDescriptionColorBox DimsDim WeightNet WeightShipping WeightRetail PriceDealer Price
302001Foundation Mount System for Barco XT - 4 x 4, Black - 4 x 4Black48x96x21582135185$3402
302002Foundation Mount System for Barco XT - 5 x 5, Black - 5 x 5Black48x96x21582184235$5314
302003Foundation Mount System for Barco XT - 6 x 6, Black - 6 x 6Black48x96x21582241297$7654
302004Foundation Mount System for Barco XT - 8 x 8, Black - 8 x 8Black48x96x27749501596$13604
302005Foundation Mount System for Barco XT - 10 x 10, Black - 10 x 10Black48x96x27749695796$21256
302006Foundation Mount System for Barco XT - 12 x 12, Black - 12 x 12Black48x96x31 09671128$30610
302007Foundation Mount System for Barco XT - 15 x 5, Black - 15 x 5Black48x96x21582494575$15942
302051Foundation Mount System for Barco XT with Trim - 4 x 4, Black - 4 x 4Black48x96x21582155206$4508
302052Foundation Mount System for Barco XT with Trim - 5 x 5, Black - 5 x 5Black48x96x21582208264$7044
302053Foundation Mount System for Barco XT with Trim - 6 x 6, Black - 6 x 6Black48x96x21582270331$10142
302054Foundation Mount System for Barco XT with Trim - 8 x 8, Black - 8 x 8Black48x96x31860548634$18030
302055Foundation Mount System for Barco XT with Trim - 10 x 10, Black - 10 x 10Black48x96x31 0742848$28172
302056Foundation Mount System for Barco XT with Trim - 12 x 12, Black - 12 x 12Black48x96x37 010231189$40568
302057Foundation Mount System for Barco XT with Trim - 15 x 5, Black - 15 x 5Black48x96x31860545631$21128
