Foundation Mount System for Unilumin UpanelS

Foundation Mount System for Unilumin UpanelS ensures fast, precise LED video wall installation with installer-friendly alignment features built in.

Engineered for greater precision and time savings, the Foundation Mount System for Unilumin UpanelS LED panels offer an economical, configurable wall mount with installer-friendly features. Built-in precision simplifies challenges, ensuring a faster, more accurate installation. Save time, gain precision—included alignment fixture tools position critical components for a flawless LED panel installation, reducing the need for realignment. Keyhole attachments and high-precision Y and Z-axis adjustments enable quick, precise installation, even on non-flat surfaces.

Warranty Ready to purchase

Product Specs

Designed specifically for Unilumin UpanelS LED panels.

Standard array sizes range from 4x4 to 12x12 plus 15x5.

Available with textured black powder coated trim or without trim.

Modular design supports any array size with no cutting or trimming required on-site.

Seismic rating: Draper is able to provide seismic rated mounting solutions when specified in advance. Please contact your sales team if seismic rating is required for your project.
