Foundation Mount System for Neoti UHD

The Foundation Mount System for Neoti UHD enables fast, precise video wall installation with a modular design and built-in alignment tools.

Engineered for greater precision and time savings, the Foundation Mount System for Neoti UHD LED panels offer an economical, configurable wall mount with installer-friendly features. Built-in precision simplifies challenges, ensuring a faster, more accurate installation. Save time, gain precision—included alignment fixture tools position critical components for a flawless LED panel installation, reducing the need for realignment. Keyhole attachments and high-precision Y and Z-axis adjustments enable quick, precise installation, even on non-flat surfaces.

Warranty Ready to purchase

Product Specs

Designed specifically for Neoti UHD LED panels.

Standard array sizes range from 4x4 to 12x12 plus 15x5.

Available with textured black powder coated trim or without trim.

Modular design supports any array size with no cutting or trimming required on-site.

Seismic rating: Draper is able to provide seismic rated mounting solutions when specified in advance. Please contact your sales team if seismic rating is required for your project.

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

Foundation Mount System for Neoti UHD

CAD

Catalog Page

Installation Instructions

CSI 3-Part Specification

Retail Pricing Table

Part Number	Description	Color	Box Dims	Dim Weight	Net Weight	Shipping Weight	Retail Price	Dealer Price
302901	Foundation Mount System for Neoti UHD - 4 x 4, Black - 4 x 4	Black		0	135	185	$3292
302902	Foundation Mount System for Neoti UHD - 5 x 5, Black - 5 x 5	Black		0	184	235	$5144
302903	Foundation Mount System for Neoti UHD - 6 x 6, Black - 6 x 6	Black		0	241	297	$7408
302904	Foundation Mount System for Neoti UHD - 8 x 8, Black - 8 x 8	Black		0	501	596	$13168
302905	Foundation Mount System for Neoti UHD - 10 x 10, Black - 10 x 10	Black		0	695	796	$20574
302906	Foundation Mount System for Neoti UHD - 12 x 12, Black - 12 x 12	Black		0	967	1128	$29686
302951	Foundation Mount System for Neoti UHD with Trim - 4 x 4, Black - 4 x 4	Black		0	155	206	$4364
302952	Foundation Mount System for Neoti UHD with Trim - 5 x 5, Black - 5 x 5	Black		0	208	264	$6818
302953	Foundation Mount System for Neoti UHD with Trim - 6 x 6, Black - 6 x 6	Black		0	270	331	$9816
302954	Foundation Mount System for Neoti UHD with Trim - 8 x 8, Black - 8 x 8	Black		0	548	634	$17450
302955	Foundation Mount System for Neoti UHD with Trim - 10 x 10, Black - 10 x 10	Black		0	742	848	$27264
302956	Foundation Mount System for Neoti UHD with Trim - 12 x 12, Black - 12 x 12	Black		0	1023	1189	$39262
