StyleLine Fixed Projection Screen

NEW! One Fixed Projection Screen—Three Standard Border Options

StyleLine distinguishes itself as a unique fixed projection screen model, available with three standard border options to suit a variety of style preferences. Select a Fine or Bold bezel, each accentuated by a Vel-Tex overlay with mitered corners for a smooth, finished look. The borderless option eliminates any visible frame for an uninterrupted viewing experience. The viewing surface easily attaches to the lightweight aluminum frame via hook and loop. Further enhance your display by using the built-in rear channel to add custom LED backlighting (from third-party sources) and create a radiant glow that’s sure to impress!

5-Year Warranty* Ready to purchase

Product Specs

Custom sizes as large as 12’ (366 cm) high and max width is 15’ (457 cm) wide. Standard sizes up to 12’ (366 cm) wide.

The full line of Draper viewing surfaces are available, including 8K-ready TecVision premium viewing surfaces.

Bezel trim options include Fine 5/8” (16 mm), Bold 3-3/16” (81 mm) or borderless.

Rear projection surfaces are only available with the Bold 3-3/16” (81 mm) trim option.

VelTex is a velvety textile that eliminates light reflections from projector over scan.

Includes ½” (13 mm) channel on the back to attach LED backlighting (by others).

Can be wall mounted or flown.

Viewing Surfaces Available:

TecVision XH700X Grey

TecVision XH800X ALR

TecVision XH900X ALR

TecVision MS1000X ALR

TecVision CS1100X ALR

TecVision XH1200X Grey

TecVision XT1000X White

TecVision XT1100X White

TecVision XT1300X White

TecVision XT1600X White

TecVision XH700X Grey NanoPerf

TecVision XH900X ALR NanoPerf

TecVision MS1000X ALR NanoPerf

TecVision XT1000X White NanoPerf

TecVision XT1100X White NanoPerf

TecVision XT1300X White NanoPerf

TecVision XT1600X White NanoPerf

TecVision XH1200X Grey NanoPerf

TecVision CS1100X ALR NanoPerf

Matt White XT1000VB

Grey XH600V

ClearSound NanoPerf XT1000V

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

StyleLine

CAD

Catalog Page

StyleLine Instructions

CSI 3-Part Specifications

Submittal

Product Page

Warranty

Sizes, Part Numbers & Prices

View all available sizes and surfaces on one page

Surface Material: Image Format: Diagonal (Image area): Bezel options: Unit of measure:

Imperial (USA)

Metric

Part number:	256001
Surface material:	Matt White XT1000VB
Image Format:	16:10
Diagonal size:	94"
Image/Viewable area:	50" x 80"
Image/Viewable area 2:
Bezel size:	50" x 80"
Case length:	0"
Height range:
Closed dimensions:
Product weight:	26 pounds
Shipping weight:	32 pounds
U.S. Retail Price:	$2064

Draper manufactures custom size screens to meet your specification. Virtually any size within the maximum shown for a given model is available. Please call for pricing on special sizes.
