Premier Electric Projection Screen

The Premier offers an affordable tab-tensioned electric projection screen that delivers a perfectly flat viewing surface for enhanced image quality.

The Premier electric projection screen comes in a sleek black pentagonal steel case, designed for wall or ceiling mounting. Its tab-tensioned construction ensures a perfectly flat viewing surface for superior image quality. RF-welded tabs provide a durable seal, eliminating separation and stickiness. Ideal for use in conference rooms, classrooms, or home theaters, the Premier offers a high-performance, cost-effective solution.

5-Year Warranty* Ready to purchase

Product Specs

Now available in new 21:9 format.

Case dimensions: 5-7/8" high x 5-1/4" deep (15 cm x 13 cm). Built-in controls and extra drop may increase case length.

Maximum image width up to 12’ (366 cm) wide, depending on surface selection. Custom sizes available.

For larger options, the Premier XL offers the same functionality as the Premier and is available in sizes up to 16' (488 cm) wide.

Steel case with black plastisol finish (standard), white optional. Includes matching endcaps with universal mounting brackets.

Image area fully framed with black. Standard 12" (30 cm) black drop at top of viewing area.

Optional white aluminum ceiling trim kit for recessed installation. Additional 12" black top drop recommended for ceiling-recessed installation.

Optional wall- or ceiling-mounting brackets for added flexibility.

Rear projection surfaces available.

Includes one 110-120V, 3-position switch (standard). Other control options are available.

UL Listed.

Viewing Surfaces Available:

TecVision XH700X Premium Contrast Grey

TecVision XH800X ALR

TecVision XH900X ALR

TecVision MS1000X ALR

TecVision CS1100X ALR

TecVision XH1200X Premium Contrast Grey

TecVision XT1000X White

TecVision XT1100X White

TecVision XT1300X White

TecVision XT1600X White

TecVision XH700X Grey NanoPerf

TecVision XH900X ALR NanoPerf

TecVision MS1000X ALR NanoPerf

TecVision XT1000X White NanoPerf

TecVision XT1100X White NanoPerf

TecVision XT1300X White NanoPerf

TecVision XT1600X White NanoPerf

TecVision XH1200X Grey NanoPerf

TecVision CS1100X ALR NanoPerf

Matt White XT1000VB

Grey XH600V

CineFlex CH1200V

CineFlex White XT700V

ClearSound NanoPerf XT1000V

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

CSI 3-Part Specifications

Submittal

BIM Object - Premier

Care and Maintenance Instructions

Product Page

Warranty

BIM Support

Sizes, Part Numbers & Prices

View all available sizes and surfaces on one page

Surface Material: Image Format: Diagonal (Image area): Voltage: Motor Options: Unit of measure:

Imperial (USA)

Metric

Part number:	101638
Surface material:	Matt White XT1000VB
Image Format:	16:10
Diagonal size:	94"
Image/Viewable area:	50" x 80"
Case length:	97"
Product weight:	50 pounds
Shipping weight:	74 pounds
U.S. Retail Price:	$3674

Draper manufactures custom size screens to meet your specification. Virtually any size within the maximum shown for a given model is available. Please call for pricing on special sizes.
