Paragon V Electric Projection Screen

Ideal for auditoriums and the largest venues, Paragon V features a durable motor for high-quality presentations.

The large size of the wall- or ceiling-mounted Paragon V electric projection screen makes it ideal for auditoriums or lecture halls. Our largest tab-tensioned screen offers a perfectly flat viewing surface for better image quality. Draper tabs create a more durable seal eliminating separation and stickiness. This heavy-duty screen provides smooth, quiet, and reliable operation.

Patent Information

5-Year Warranty* Ready to purchase

Product Specs

Case dimensions 13-1/4"high x 12" deep (34 cm x 30 cm). Optional extra drop may increase case length.

Maximum image width up to 24' (732 cm) wide, depending on surface selection.

Image area fully framed with black. Standard 12" (30 cm) black drop at top of viewing area.

Includes extruded aluminum case with white finish. Optional wall-mounting brackets and ceiling trim flange kit.

Bottom closure panel provides easy access for service or maintenance.

Rear projection surfaces available.

Includes a 110V, 3-position switch (standard). Low-voltage modules and controls or 220V options are available.

Custom sizes available.

UL Listed.

Viewing Surfaces Available:

TecVision XH700X Grey

TecVision XH800X ALR

TecVision XH900X ALR

TecVision MS1000X ALR

TecVision CS1100X ALR

TecVision XH1200X Grey

TecVision XT1000X White

TecVision XT1100X White

TecVision XT1300X White

TecVision XT1600X White

Matt White XT1000VB

Grey XH600V

CineFlex CH1200V

CineFlex White XT700V

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

CSI 3-Part Specifications

Paragon V Submittal

BIM Object

Care and Maintenance Instructions

Product Page

Warranty

BIM Support

Sizes, Part Numbers & Prices

View all available sizes and surfaces on one page

Surface Material: Image Format: Diagonal (Image area): Voltage: Unit of measure:

Imperial (USA)

Metric

Part number:	114616
Surface material:	Matt White XT1000VB
Image Format:	16:10
Diagonal size:	234"
Image/Viewable area:	124" x 198"
Case length:	220 ¼"
Product weight:	395 pounds
Shipping weight:	750 pounds
U.S. Retail Price:	$9646

Draper manufactures custom size screens to meet your specification. Virtually any size within the maximum shown for a given model is available. Please call for pricing on special sizes including the new 21:9 format.
