Ultimate Access XL V Electric Projection Screen

Ideal for large venues, the Ultimate Access XL V offers a tab-tensioned, ceiling-recessed screen with complete concealment in sizes up to 22 feet.

The Ultimate Access XL V ceiling-recessed, tab-tensioned electric screen meets the demands of major venues like conference centers and ballrooms. Its case includes a motorized trap door for smooth screen descent and a ceiling closure panel that fully conceals the screen with no visible fasteners. The tab-tensioned design ensures a flat viewing surface for superior image quality, with RF-welded tabs preventing separation and stickiness. A bottom access panel simplifies maintenance, and installing the case early prevents damage and allows the screen to be added later.

5-Year Warranty* Ready to purchase

Product Specs

Case dimensions are 14-1/16" high x 11" deep (36 cm x 28 cm), includes trim flange.

Built-in controls and mounting brackets may increase case dimensions. See Submittal for details.

Maximum image width up to 22' (671 cm) wide, depending on surface selection. Custom sizes available

Image area fully framed with black. Standard 12" (30 cm) black drop at top of viewing area.

Adjustable or removable hoisting brackets included for easy lifting during installation.

Sliding brackets on top allow for mounting adjustments; inside brackets accommodate different screen sizes.

Ceiling closure panel can be finished by a contractor to match the ceiling.

Independently motorized ceiling closure panel opens into the case

Junction box and 110V three-position wall switch included for recessed wall mounting.

Low voltage video interface or other controls can be built into the housing for below ceiling access.

White case standard, black available upon request

Custom sizes available

UL Listed.

Viewing Surfaces Available:

TecVision XH700X Premium Contrast Grey

TecVision XH800X ALR

TecVision XH900X ALR

TecVision MS1000X ALR

TecVision CS1100X ALR

TecVision XH1200X Premium Contrast Grey

TecVision XT1000X White

TecVision XT1100X White

TecVision XT1300X White

TecVision XT1600X White

Matt White XT1000VB

Grey XH600V

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

CSI 3-Part Specifications

Ultimate Access XL V - Submittal

BIM Object

Care and Maintenance Instructions

Product Page

Warranty

BIM Support

Sizes, Part Numbers & Prices

View all available sizes and surfaces on one page

Surface Material: Image Format: Diagonal (Image area): Voltage: Motor Options: Unit of measure:

Imperial (USA)

Metric

Part number:	145001
Surface material:	Matt White XT1000VB
Image Format:	16:10
Diagonal size:	189"
Image/Viewable area:	100" x 160"
Image/Viewable area 2:
Overall size:
Case length:	186 ¾"
Height range:
Closed dimensions:
Product weight:	211 pounds
Shipping weight:	574 pounds
U.S. Retail Price:	$11306

Draper manufactures custom size screens to meet your specification. Virtually any size within the maximum shown for a given model is available. Please call for pricing on special sizes.
