FlexShade ZIP XL

Outdoor ZIP Shading System for Sizes up to 25 feet wide

FlexShade ZIP XL uses an improved Zip 127 Headbox with an integrated cradle support system to minimize deflection and allow wider outdoor shade widths. The ZIP feature captures the fabric's edge, resulting in secure fabric retention and improved light control. Cushioning pads dampen fabric movement under wind load and panels are held in place. As an exterior window shading system, it lowers HVAC expenses by preventing heat from entering a building. In outdoor covered spaces—such as garages, porches, or commercial food service areas—it filters harsh glare and protects against wind and insects, creating a pleasant outdoor experience. The FlexShade Zip XL can be paired with an Obstacle Detection Motor for added fabric protection.

Patent Information

Fabric Options

Large Format Printing

Warranty Ready to purchase

Product Specs

Available in sizes up to 25' wide x 15' high (762 cm x 457 cm), depending on fabric selection.

Uses ZIP 127 headbox: 5” H (127 mm) headbox. Two Headbox Styles: angled and curved.

For added fabric protection FlexShade ZIP XL can be paired with an Obstacle Detection Motor.

Hardware finish is textured powder coat available in white, black, ivory, sand, charcoal bronze, or silver (smooth finish). Custom powder coat colors available.

Side guides can be jamb or face mounted.

No light gap at side channels for complete edge blackout system. Side channel width is 1-3/4" (44 mm).

Can serve as an operable insect screen or room divider.

Provides excellent protection against wind.

Weighted hem bar to stabilize shade during operation.

Available with an RTS Radio Technology Somfy obstacle detection motor or standard motors.

Product designed for exterior and interior use.

UL Listed.

ANSI/WCMA A100.1-2022 Child Safety Standard

Effective June 1, 2024, in compliance with the updated ANSI/WCMA A100.1-2022 child safety standard, all Draper window shades operated by a bead chain will be furnished with a tensioned hold-down device that is permanently attached and partially disables the product if not installed correctly. This hold-down should be installed with tension on the chain.

All bead chain operated window shades will include:

Permanently installed spring-loaded tensioned hold-down device
Approved permanent warning label attached
Approved mechanical fasteners for the tension device included. Screws provided are not suitable for all mounting surfaces. The installer is responsible for secure mounting using appropriate hardware for the site conditions. Consult with contractors and builders as needed.

If the tension device is not installed with appropriate tension on the bead chain, the shade will be rendered partially inoperable. If installed properly, the tension device will prevent the creation of a hazardous loop and will maintain tension on the bead chain.

Learn more about the new child safety standard

At the link below, you can see more information about the new child safety standard, mounting methods for the tensioned hold-down device, alternatives to bead chain products, and more.

Click here for more information

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

CSI 3-Part Specification

Submittal

BIM Object

Cleaning: Outdoor Shades

Warranty

BIM Support

Part Numbers

Videos

FlexShade Zip Exterior Motorized Roller Shades - Part 2: Cassette Mounting

To Mount the headbox on a Wall or ceiling using cassette brackets, simply attach the cassette brackets to the mounting surface using #10 flat head screws. It is the installer’s responsibility to choose the length of #10 flat head screw appropriate for the mounting surface. The mounting brackets must be installed level with each other. Be sure to drive the screws in flush with bracket.

FlexShade Zip Exterior Motorized Roller Shades - Part 2B: Direct Mount Instructions

To mount the headbox permanently, you will first need to attach the mounting brackets to the headbox as a spacer between the headbox and the wall. Be sure to leave a 1¾" (45mm) gap between the end cap and mounting bracket.

FlexShade Zip Exterior Motorized Roller Shades - Part 3: Installing Side Channels

This video will cover methods for installing side channels. For instructions on preparing your site for proper product installation and mounting of the FlexShade Zip Motorized Shade headbox, please see the previous instructional videos in this series. These instructions do not apply for installations using the ZIP 127 angled headbox.

FlexShade Zip Exterior Motorized Roller Shades - Part 4: Limit Setting

To begin programming with your remote, first connect power to one motor. Select a transmitter channel to assign that particular motor unit. Hold the UP and DOWN buttons until the motor jogs, and then release. Note the motor direction. To reverse the direction, hold the MY/STOP button for 5 seconds until the motor jogs. Failure to complete this step can only be corrected with a motor reset.

FlexShade Zip Exterior Motorized Roller Shades – Part 5: Advanced Programming

This video will cover advanced programming for proper operation of the shade. For instructions on proper product installation and mounting of the FlexShade Zip Motorized Shade as well as initial limit setting for the Somfy RTS Shade Motor, please see the previous instructional videos in this series.

Podcast: Window shades improve workplace comfort and productivity

Jeff Miller, our Solar Control Product Manager, discusses how solar shading can improve the comfort and productivity of workers, and improve your company's bottom line.

Wind Tunnel Testing the FlexShade Zip and Zip XL

When a shade system is being used outdoors, it’s important that it be as resistant as possible to wind and weather. Our FlexShade ZIP exterior roller shade is often used to protect outdoor spaces from sun, heat, wind, and insects. We recently sent a team to learn exactly that.

Somfy: Initial Programming & Limit Setting R-01

Part of a series of how-to videos produced by Somfy Systems, this video discusses Initial Programming & Limit Setting.

Somfy: Limit Adjustment in User Mode R-04

Part of a series of how-to videos produced by Somfy Systems, this video discusses Limit Adjustment in User Mode R-04.

Somfy: Factory Reset - AC Motors

Part of a series of how-to videos produced by Somfy Systems, this video discusses Factory Resetting - AC Motors

Somfy: Add or Delete a Transmitter

Part of a series of how-to videos produced by Somfy Systems, this video discusses how to Add or Delete a Transmitter.

Somfy: Setting the "MY Favorite" Position

Part of a series of how-to videos produced by Somfy Systems, this video discusses how to Set the "MY Favorite" Position.

Case Studies

Outdoor Shades Doubled This Restaurant's Seating Capacity

If there’s one thing popular restaurants never seem to have enough of, it’s space. The Cow: An Eatery is no exception. The Cow is in beautiful Morrison, Colorado, home to Red Rocks Amphitheatre and Red Rocks Park. The restaurant has a busy mix of tourists and local regulars.

Private Residence - Austin, TX

Motorized FlexShade ZIP XL Exterior Shade featuring Phifer TuffScreen installed at private residence in Austin, TX

Private residence - Dallas, TX

FlexShade ZIP and FlexShade ZIP XL window shade provide a barrier from the sun, weather, and insects on a poolside patio in a private residence in Dallas, TX

Private Residence – Orlando, FL

FlexShade ZIP XL Exterior Motorized Shades with Mermet E Screen 3% Charcoal/Grey installed at a Private Residence in Orlando, FL

Private Residence – The Villages, FL

Digitally Printed Motorized FlexShade Battery Window Shades with Oslo RD White installed at a Private Residence in The Villages, FL

Short Hills Country Club - Short Hills, NJ

Flexshade ZIP and FlexShade ZIP XL motorized roller shades featuring Phifer SheerWeave SW2400 3% open fabric in Charcoal color installed at Short Hills Country Club in Short Hills, NJ.
