Motorized FlexStyle RTS AC

Radio Technology Motorized Shade Built-In Radio Receiver 3-Wire Line Voltage Motor

A luxury open roll shade, Motorized FlexStyle RTS AC features a built-in radio receiver for wireless shade control. The easy-to-program handheld control options with plug and play capabilities make this shade an excellent choice for any residential space, as well as the office, boardroom and small commercial settings. Decorative and well-designed mounting brackets conceal fasteners in nine attractive designer colors and plated finishes.

Hardware Options

Fabric Options

Large Format Printing

Warranty Ready to purchase

Product Specs

CHILD SAFETY NOTICE: This product complies with ANSI/WCMA A100.1-2022-Child Safety Standard and has been Certified Best for Kids™ by the Window Covering Safety Council.

Open roll shade available in single roller option and can be coupled to reduce the number of motors required.

Accommodates a 2-¾” (70 mm) bundle diameter max and up to 8’ (244 cm) width.

Unit includes a 3-wire radio line voltage motor, parallel wiring, and electronic programmable limits.

AC motors use line voltage. Motors can be parallel wired (daisy chained).

Serial and dry contact interfaces available.

Wireless wall switches available in 1, 2, 3, 4, or 5 channels. Handheld remotes are available in 1, 4, or 16 channels.

Secure moisture resistant connection to line voltage using an M12 Connector or Plug & Play option using three-prong NEMA plug.

Optional sun sensor or timer with on-screen display.

App control is an optional feature.

Stylish cast aluminum brackets available in nine designer colors and plated finishes. Brushed Nickel, Brushed Gold, Antique Bronze, and Chrome come with a plated coating. Taupe, Grey, Black, White, and Warm White are painted. Or choose Primer Grey for hardware that is ready for you to paint.

Choose from a wide range of fabrics in a variety of colors, textures, and opacities to customize any room's décor.

Shades can be customized with graphics, patterns, or custom color matches, including color matching libraries such as Sherwin-Williams and Pantone.

Product designed for interior use.

ANSI/WCMA A100.1-2022 Child Safety Standard

Effective June 1, 2024, in compliance with the updated ANSI/WCMA A100.1-2022 child safety standard, all Draper window shades operated by a bead chain will be furnished with a tensioned hold-down device that is permanently attached and partially disables the product if not installed correctly. This hold-down should be installed with tension on the chain.

All bead chain operated window shades will include:

Permanently installed spring-loaded tensioned hold-down device
Approved permanent warning label attached
Approved mechanical fasteners for the tension device included. Screws provided are not suitable for all mounting surfaces. The installer is responsible for secure mounting using appropriate hardware for the site conditions. Consult with contractors and builders as needed.

If the tension device is not installed with appropriate tension on the bead chain, the shade will be rendered partially inoperable. If installed properly, the tension device will prevent the creation of a hazardous loop and will maintain tension on the bead chain.

Learn more about the new child safety standard

At the link below, you can see more information about the new child safety standard, mounting methods for the tensioned hold-down device, alternatives to bead chain products, and more.

Click here for more information

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

Motorized FlexStyle RTS AC

Catalog Page

Installation Instructions

Submittal

TB2024-3-SH_Best-for-Kids

Warranty

Part Numbers

Videos

FlexStyle - Draper at CEDIA 2023

Tyler Reece discusses FlexStyle decorative roller shades for residential applications at CEDIA 2023.

How To Install FlexStyle Window Shades by Draper, Inc.

Learn to install one of the easiest shades Draper has to offer!

How Draper Makes a Shade

Go behind the scenes to see how Draper custom creates each new window shade. Our integrated process means you get a higher quality product faster.

Somfy: Initial Programming & Limit Setting R-01

Part of a series of how-to videos produced by Somfy Systems, this video discusses Initial Programming & Limit Setting.

Somfy: Limit Adjustment in User Mode R-04

Part of a series of how-to videos produced by Somfy Systems, this video discusses Limit Adjustment in User Mode R-04.

Somfy: Factory Reset - AC Motors

Part of a series of how-to videos produced by Somfy Systems, this video discusses Factory Resetting - AC Motors

Somfy: Add or Delete a Transmitter

Part of a series of how-to videos produced by Somfy Systems, this video discusses how to Add or Delete a Transmitter.

Somfy: Setting the "MY Favorite" Position

Part of a series of how-to videos produced by Somfy Systems, this video discusses how to Set the "MY Favorite" Position.

Case Studies

Corporate Offices – Dayton, OH

Manual FlexShade Window Shades with Phifer SheerWeave®?- Basic 5% White/Platinum installed at a Corporate Office

Goodyear City Hall & Library - Goodyear, AZ

Motorized FlexShade Window Shades with Mermet E Screen 3% Charcoal installed in the Goodyear City Hall & Library.

Private Residence – Long Beach, CA

Motorized FlexStyle Window Shades with Phifer SheerWeave 2700 Oyster 3% installed in a Private Residence located in Long Beach, CA

Related Motors & Accessories

Motors and Controls for this shade.
