Targa Electric Projection Screen

The Targa electric projection screen provides economical motorization for conference rooms and classrooms. Easy to install.

The Targa projection screen is renowned for its affordability and popularity, making it perfect for conference and lecture halls, hospitals, hotels, restaurants, boardrooms, and churches. It features a stylish pentagonal steel case with matching endcaps that serve as universal mounting brackets, facilitating simple wall or ceiling installation.

5-Year Warranty* Ready to purchase

Product Specs

Case dimensions 5-7/8"h x 5-1/4" d (15 cm x 13 cm) including endcaps with universal mounting brackets. Optional built-in controls and extra drop may increase case length. Contact Draper for dimensions.

Maximum image width up to 12' (366 cm) wide, depending on surface selection.

Housed in pentagonal steel case with a scratch-resistant white polyester finish (standard). Black available upon request. Larger sizes require a different case design and can be found in Targa XL.

Includes matching endcaps with universal mounting brackets. Optional floating wall brackets grip the screen securely anywhere along the back of the case, and are barely visible

NTSC, HDTV, and 16:10 formats have image area framed with black on all four sides. Black side borders are available upon request for AV.

Black drop standard, depending on screen size. Extra drop above image area available upon request.

Available with ceiling trim kit for ceiling-recessed installation. An additional 12" (30 cm) top drop is recommended for ceiling-recessed installation.

Includes one 110-120V, 3-position switch (standard). Other control options are available.

Custom sizes available.

UL Listed.

Viewing Surfaces Available:

Matt White XT1000E

Contrast Grey XH800E

ClearSound White Weave XT900E

Chroma Key Green

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

CSI 3-Part Specifications

Submittal

BIM Object - Targa

Care and Maintenance Instructions

Product Page

Warranty

BIM Support

Sizes, Part Numbers & Prices

View all available sizes and surfaces on one page

Surface Material: Image Format: Diagonal (Image area): Voltage: Motor Options: Unit of measure:

Imperial (USA)

Metric

Part number:	116367
Surface material:	Matt White XT1000E
Image Format:	16:10
Diagonal size:	94"
Image/Viewable area:	50" x 80"
Overall size:	62" x 83 1/2"
Case length:	90 ½"
Product weight:	40 pounds
Shipping weight:	57 pounds
U.S. Retail Price:	$1588

Draper manufactures custom size screens to meet your specification. Virtually any size within the maximum shown for a given model is available. Please call for pricing on special sizes.
