StageScreen Portable Folding Screens & Drapes

StageScreen features a modular truss that delivers a strong, rigid projection screen with superior size flexibility that boosts ROI for AV rentals.

StageScreen offers versatile, free-standing or flown sizes using interchangeable frame sections for different viewing formats. This flexibility streamlines inventory and boosts ROI for AV rentals. Its 8" truss design is sturdier than traditional folding screens, and the Draper DuraLoop bungee system ensures quick, easy surface attachment. With self-centering tension for a flat, high-quality image, StageScreen is perfect for stages, theaters, and large venues.

5-Year Warranty* Ready to purchase

Product Specs

Maximum image area width 75’ (22.86 m). Maximum image area height 22’6” (6.9 m).

May be wall-mounted, suspended, or free-standing.

Frame available in a black finish.

No hinges, snaps, or handy cranks required. Color-coded frame and instructions ensure fast and easy assembly.

Frame sections are connected with permanently attached threaded links and guide pins.

Viewing surface attaches easily to perimeter frame with DuraLoop bungee cord loops.

The image area of each screen is exact and true to format.

Includes wheeled heavy-duty polyethylene carrying case.

Custom sizes available.

Viewing Surfaces Available:

TecVision XH700X Grey

TecVision XH800X ALR

TecVision XH900X ALR

TecVision MS1000X ALR

TecVision CS1100X ALR

TecVision XH1200X Grey

TecVision XT1000X White

TecVision XT1100X White

TecVision XT1300X White

TecVision XT1600X White

Matt White XT1000VB

CineFlex CH1200V

CineFlex White XT700V

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

CSI 3-Part Specifications

StageScreen Submittal

Care and Maintenance Instructions

Product Page

Warranty

Assembly Maps

Create Assembly Map for a Custom Size

Assembly Maps for Standard Size Frames

4:3 NTSC Format

16:9 HDTV Format

16:10 Format

Multi-Format

72" x 96" | 183 x 244 cm
PDF document

90" x 120" | 229 x 305 cm
PDF document

108" x 144" | 274 x 366 cm
PDF document

126" x 168" | 320 x 427 cm
PDF document

144" x 192" | 366 x 488 cm
PDF document

162" x 216" | 412 x 549 cm
PDF document

180" x 240" | 457 x 610 cm
PDF document

216" x 288" | 549 x 732 cm
PDF document

270" x 360" | 686 x 914 cm

Assembly Maps for Standard Legs

Leg "A" Assembly Map
PDF document

Leg "B" Assembly Map
PDF document

Leg "C" Assembly Map
PDF document

Leg "D" Assembly Map

Sizes, Part Numbers & Prices

View all available sizes and surfaces on one page

Complete system or surface only: Surface Material: Image Format: Diagonal (Image area): Unit of measure:

Imperial (USA)

Metric

Part number:	383504
Surface material:	Matt White XT1000VB
Image Format:	16:10
Diagonal size:	113"
Image/Viewable area:	60" x 96"
Overall size:	76 1/2" x 112 1/2"
Product weight:	79 pounds
Shipping weight:	89 pounds
U.S. Retail Price:	$5818

Draper manufactures custom size screens to meet your specification. Virtually any size within the maximum shown for a given model is available. Please call for pricing on special sizes.
