Ropewalker Electric Projection Screen

Elevate presentations with the Ropewalker: a sleek integrated screen and lift with a 34-foot drop, ideal for grand venues. Includes safety cables.

Meet the Ropewalker—your new go-to for stunning presentations! This cutting-edge system merges a screen and lift into a sleek ceiling-recessed box, removing the need for extra black drop material. With a remarkable 34-foot (10-meter) vertical drop, it effortlessly places a large electric screen high above the audience, making it ideal for grand spaces like hotel ballrooms, conference centers, theaters, and gymnasiums. Choose from tab-tensioned or free-hanging surfaces and enjoy the added safety of built-in cables. Transform your viewing experience with the Ropewalker!

5-Year Warranty* Ready to purchase

Product Specs

Image size up to 18' x 18' (548 cm x 548 cm) either tab-tensioned or non-tensioned surfaces .

Travel range up to 34' (1,067 cm).

Speed - 20' per minute (120V) / 17' per minute (220V).

Includes safety cables for projection screen housing that descends into room.

Includes single station wall switch, other control options available.

Viewing Surfaces Available:

TecVision XH700X Premium Contrast Grey

TecVision XH800X ALR

TecVision XH900X ALR

TecVision MS1000X ALR

TecVision CS1100X ALR

TecVision XH1200X Premium Contrast Grey

TecVision XT1000X White

TecVision XT1100X White

TecVision XT1300X White

TecVision XT1600X White

Matt White XT1000VB

Grey XH600V

Matt White XT1000E

Contrast Grey XH800E

Supporting Documents

Click the and icons to navigate the folders. Click the document name to download.

Installation Instructions

Ropewalker - Submittal

BIM Object

Care and Maintenance Instructions

Product Page

Warranty

BIM Support

Sizes, Part Numbers & Prices

View all available sizes and surfaces on one page

Surface Material: Image Format: Diagonal (Image area): Unit of measure:

Imperial (USA)

Metric

Part number:	150016
Surface material:	Matt White XT1000VB
Image Format:	16:10
Diagonal size:	76"
Image/Viewable area:	40" x 64"
Image/Viewable area 2:
Overall size:	52" x 69 1/2"
Height range:
Closed dimensions:
Product weight:	370 pounds
Shipping weight:	771 pounds
U.S. Retail Price:	$29948

Draper manufactures custom size screens to meet your specification. Virtually any size within the maximum shown for a given model is available. Please call for pricing on special sizes.
